Wildlife Viewing Activities from Non-consumptive Ocean Recreation Study - Last Trip Panel Responses Summarized to Planning Units, Surfrider, 2010

Citation:

Citation Information:

Originator: Ecotrust,Surfrider Foundation,NaturalEquity
Publication Date: December, 2010
Title: Wildlife Viewing Activities from Non-consumptive Ocean Recreation Study - Last Trip Panel Responses Summarized to Planning Units, Surfrider, 2010
Geospatial Data Presentation Form: vector digital data
Larger Work Citation:

Citation Information:

Originator: Surfrider Foundation,NaturalEquity,Ecotrust
Publication Date: March 3, 2011
Title: Non-Consumptive Ocean Recreation in Oregon: Human Uses, Economic Impacts & Spatial Data
Online Linkage: http://oregon.surfrider.org/files/2011/03/OregonNonconsumptiveStudy_comp.pdf

Description:

Abstract:
The data summarized in this particular layer are the Last trip shore activities group of respondses. This group was an aggregation of repondses for the following activities: beach going, scenic enjoyment, storm watching, biking/hiking, off-road vehicles, and photography. Results from this group were summarized into cumulative polygon data, using the Oregon spatial planning unit grid.
Purpose: These data were collected to create a baseline of use patterns for Oregon's recreational non-consumptive ocean users.
Supplemental Information:
The These data include only the last trip data collected over the summer of 2010. These data were collected as part of Oregon's Territorial Sea Plan revision.
This data, and the larger study referenced at the above URL, provides high-quality spatially explicit information on current non-consumptive recreational ocean use on the Oregon coast. Specifically, the study: identifies and estimates the size of the Oregon non-consumptive recreational ocean user community; supplies spatially explicit information on current non-consumptive ROU use including activity, extent, and demographics.

Time Period of Content:

Time Period Information:

Range of Dates/Times:

Beginning Date: 2009
Beginning Time: Unknown
Ending Date: 2010
Ending Time: Unknown

Currentness Reference: publication date

Status:

Progress: Complete
Maintenance and Update Frequency: As needed

Spatial Domain:

Bounding Coordinates:

West Bounding Coordinate: -124.833224
East Bounding Coordinate: -123.409179
North Bounding Coordinate: 46.313263
South Bounding Coordinate: 41.980516

Keywords:

Theme:

Theme Keyword Thesaurus: N/A
Theme Keyword: Non-consumptive survey
Theme Keyword: Last trip data
Theme Keyword: panel data

Access Constraints: None. Public Data
Use Constraints:
See the full PDF of the larger study to fully understand the methods used to collect this information, and the limitations implied. While these data were created to fit with the MMS sub-regional planning units, the layer has no legal uses.
Point of Contact:

Contact Information:

Contact Organization Primary:

Contact Organization: Ecotrust
Contact Person: Jon Bonkoski

Contact Position: Senior GIS Analyst
Contact Address:

Address Type: mailing and physical address
Address:
721 NW 9th Ave. Suite 200

City: Portland
State or Province: OR
Postal Code: 97209

Data Set Credit: Funding was provided by the David and Lucile Packard Foundation
Native Data Set Environment: Microsoft Windows XP Version 5.1 (Build 2600) Service Pack 3; ESRI ArcCatalog 9.3.0.1770

Logical Consistency Report:
Data editing protocol was developed to ensure a consistent and accurate dataset. Each group (boating, ocean, shore, wildlife) were edited based on certain criteria. Boating group:
1) All points must be in a waterbody, including, ocean, bay, and estuary.
Ocean group:
1) Edited all points that fell on land so they would only be in water.
2) Determined if a point is too far offshore to realistically be accessed by human-powered methods, with the exception being offshore reefs, which resulted in the data being removed.
Shore group:
1) Edited all points that fell in water so they would only be on land.
2) Removed points that were too far inland to realistically have any influence on the shore region.
Wildlife group:
1) Points could be either in the water or on land, but should be within a reasonable distance to shoreline.

Lineage:

Process Step:

Process Description:
The survey responses were downloaded from the internet and the spatial data were updated with coordinate system information (WGS 1984). The spatial data were then re-projected into Albers Conical Equal Area (NAD 83). To move the process forward, the data were then imported into a geodatabase built for this analysis. The original table format was well suited for collecting information; however, it was not appropriate for the data analysis needed, and as a result, the data tables needed to be reorganized. The purpose of this reorganization was to create an activity matrix for each layer. The matrices were built so that the data could be summarized to the PU grid cells, which required that the information needed to be a number field. To do this, we converted data into an activity matrix where a number field (type - double) was added to the spatial layer for each activity (e.g., beach going, biking/hiking, surfing, etc.). The end result was a new field for each activity that was then updated with a binary value of 0 or 1 for every activity point (e.g., every surfing activity point was updated with a 1 in the matrix under the surfing column).
Process Time: 20:10:11
Process Contact:

Contact Information:

Contact Person Primary:

Contact Person: Jon Bonkoski
Contact Organization: Ecotrust

Contact Position: Senior GIS Analyst
Contact Address:

Address Type: mailing and physical address
Address: 721 NW Ninth Ave . Suite 200
City: Portland
State or Province: Oregon
Postal Code: 97209
Country: USA

Contact Voice Telephone: 5034670804
Contact Facsimile Telephone: 5032221517
Contact Electronic Mail Address: jbonkoski@ecotrust.org
Hours of Service: business hours
Contact Instructions: Email preferred

Cloud Cover: 0

Direct Spatial Reference Method: Vector
Point and Vector Object Information:

SDTS Terms Description:

SDTS Point and Vector Object Type: G-polygon
Point and Vector Object Count: 273

Horizontal Coordinate System Definition:

Planar:

Map Projection:

Map Projection Name: Lambert Conformal Conic
Lambert Conformal Conic:

Standard Parallel: 43
Standard Parallel: 45.5
Longitude of Central Meridian: -120.5
Latitude of Projection Origin: 41.75
False Easting: 1312335.958005
False Northing: 0

Planar Coordinate Information:

Planar Coordinate Encoding Method: Coordinate Pair
Coordinate Representation:

Abscissa Resolution: 0
Ordinate Resolution: 0

Planar Distance Units: international feet

Geodetic Model:

Horizontal Datum Name: North American Datum of 1983
Ellipsoid Name: Geodetic Reference System 80
Semi-major Axis: 6378137
Denominator of Flattening Ratio: 298.257

Detailed Description:

Entity Type:

Entity Type Label: Panel_Lasttrip_Wildlife_PU

Attribute:

Attribute Label: FID
Attribute Definition: Internal feature number.
Attribute Definition Source: ESRI
Attribute Domain Values:

Unrepresentable Domain: Sequential unique whole numbers that are automatically generated.

Attribute:

Attribute Label: GRIDID
Attribute Definition: GRID cell ID

Attribute:

Attribute Label: Join_Count
Attribute Definition: Number of activity points summarized to this grid cell

Attribute:

Attribute Label: NAME
Attribute Definition: Name of activity
Attribute Definition Source: Knowledge Networks

Attribute:

Attribute Label: OBJECTID
Attribute Definition: original point OBJECTID

Attribute:

Attribute Label: Shape
Attribute Definition: Feature geometry.
Attribute Definition Source: ESRI
Attribute Domain Values:

Unrepresentable Domain: Coordinates defining the features.

Attribute:

Attribute Label: Shape_Area
Attribute Definition: Area of feature in internal units squared.
Attribute Definition Source: ESRI
Attribute Domain Values:

Unrepresentable Domain: Positive real numbers that are automatically generated.

Attribute:

Attribute Label: Shape_Leng

Distributor:

Contact Information:

Contact Person Primary:

Contact Person: Tanya C. Haddad
Contact Organization: Oregon Coastal Management Program

Contact Address:

Address Type: mailing and physical address
Address: 800 NE Oregon St
City: Portland
State or Province: OR
Postal Code: 97232
Country: USA

Contact Voice Telephone: 9716730962
Contact Facsimile Telephone: 9716730911
Contact Electronic Mail Address: tanya.haddad@state.or.us
Hours of Service: Regular Business Hours
Contact Instructions: Email preferred

Resource Description: Downloadable Data
Distribution Liability:
These data and associated data files are provided "as is," without warranty to their performance, merchantable state, or fitness for any particular purpose. The entire risk associated with the results and performance of these data is assumed by the user. This data is not for navigational or legal purposes.
Standard Order Process:

Digital Form:

Digital Transfer Information:

Transfer Size: 0.036

Available Time Period:

Time Period Information:

Single Date/Time:

Calendar Date: 2009
Time of Day: Unknown

Metadata Date: 3/19/2011
Metadata Review Date:
Metadata Future Review Date:
Metadata Contact:

Contact Information:

Contact Organization Primary:

Contact Organization: Ecotrust
Contact Person: Jon Bonkoski

Contact Position: Senior GIS Analyst
Contact Address:

Address Type: mailing and physical address
Address:
721 NW 9th Ave. Suite 200

City: Portland
State or Province: OR
Postal Code: 97209

Metadata Standard Name: FGDC Content Standards for Digital Geospatial Metadata
Metadata Standard Version: FGDC-STD-001-1998
Metadata Time Convention: local time
