West Coast Surficial Geolgic Habitat, version 3.6.1, ATSML, 2011

Citation:

Citation Information:

Originator: Chris Romsos, Andrew Lanier, Melinda Agapito,Chris Goldfinger
Publication Date: December 2011
Title: West Coast Surficial Geolgic Habitat, version 3.6.1, ATSML, 2011
Geospatial Data Presentation Form: vector digital data
Publication Information:

Publication Place: Corvallis, OR
Publisher: Active Tectonics and Seafloor Mapping Lab, COAS, Oregon State University

Description:

Abstract: Surficial Geologic Habitat for the Washington, Oregon and California continental margins.
Purpose:
These data were originally developed to support the identification and delineation of Essential Fish Habitat (EFH) for west coast groundfish. Subsequently, they have been revised through hand interpretation in support of Oregon's efforts to implement Marine Reserves within the Territorial Sea.
Version 3.6 was developed in support of Oregon's Territorial Sea Planning process for the short term need of wave energy facilities siting.

Supplemental Information:
This version of the data, v3.6.1, is identical to v3.6 with the exception of the addition of kelp canopy extent burned in and reclassified by TNC staff as a proxy for habitat type 'Rock'. Canopy extent was defined as the maximum identified across ODFW's Modern Kelp Surveys in years 1990, 1996-99, and ODFW's 2010 digital multispectral imagery (DMSI) of kelp canopy for southern Oregon (Cape Arago to Brookings).
Time Period of Content:

Time Period Information:

Range of Dates/Times:

Beginning Date: Unknown
Beginning Time: Unknown
Ending Time: Unknown

Currentness Reference: publication date

Status:

Progress: In work
Maintenance and Update Frequency: Continually

Spatial Domain:

Bounding Coordinates:

West Bounding Coordinate: -126.490895
East Bounding Coordinate: -116.134588
North Bounding Coordinate: 48.580104
South Bounding Coordinate: 31.835378

Keywords:

Theme:

Theme Keyword Thesaurus: N/A
Theme Keyword: Seafloor
Theme Keyword: Habitat
Theme Keyword: Benthic
Theme Keyword: Geophysical
Theme Keyword: Marine
Theme Keyword: Essential Fish Habitat (EFH)

Theme:

Theme Keyword Thesaurus: IOOS Vocabulary Version 1
Theme Keyword: Bottom Character
Theme Keyword: IOOS
Theme Keyword: Integrated Ocean Observing System

Theme:

Theme Keyword Thesaurus: International Organization for Standardization
Theme Keyword: geoscientificInformation
Theme Keyword: imageryBaseMapsEarthCover
Theme Keyword: Oceans

Place:

Place Keyword Thesaurus: N/A
Place Keyword: West Coast
Place Keyword: Washington
Place Keyword: Oregon
Place Keyword: California
Place Keyword: Northeast Pacific Ocean

Access Constraints: None
Use Constraints:
Use of these data is restricted to entities of the State of Oregon for internal evaluation only. Any use of these data constitutes an understanding that this data-set represents a work-in-progress which is accompanied by no guarantee of accuracy.
Point of Contact:

Contact Information:

Contact Organization Primary:

Contact Organization: Active Tectonics & Seafloor Mapping Lab
Contact Person: Chris Romsos

Contact Position: Faculty Research Assistant
Contact Address:

Address Type: mailing address
Address: 104 COAS Admin. Bldg., Oregon State University
City: Corvallis
State or Province: OR
Postal Code: 97330
Country: USA

Contact Voice Telephone: 541-737-2898
Contact Electronic Mail Address: cromsos@coas.oregonstate.edu

Data Set Credit:
Please credit the Active Tectonics & Seafloor Mapping Lab when using this dataset. Subsequent modification was performed in 2011, as noted, by collaborators of ODFW at NOAA's Biogeography Branch and by contracted staff at The Nature Conservancy in Oregon.
Native Data Set Environment: Microsoft Windows Vista Version 6.1 (Build 7601) Service Pack 1; ESRI ArcCatalog 9.3.1.4000

Attribute Accuracy:

Attribute Accuracy Report:
Use of these data is restricted to entities of the State of Oregon for internal evaluation only. Any use of these data constitutes an understanding that this data-set represents a work-in-progress which is accompanied by no guarantee of accuracy.
Logical Consistency Report:
No data quality information is provided with this Version 3.x of the Oregon SGH map. Data Quality information was released with Version 1.1 and can be used with caution here. Melinda Agapito's MS Thesis (Oregon State University, 2008) covers thematic map accuracy within the territorial sea of Oregon.
Positional Accuracy:

Horizontal Positional Accuracy:

Horizontal Positional Accuracy Report:
Use of these data is restricted to entities of the State of Oregon for internal evaluation only. Any use of these data constitutes an understanding that this data-set represents a work-in-progress which is accompanied by no guarantee of accuracy.
Lineage:

Source Information:

Source Citation:

Citation Information:

Originator: Romsos, C.G.
Publication Date: 2004
Title: West Coast Surficial Geolgic Habitat, Version 1
Other Citation Details: Mapping Surficial Geologic Habitats of the Oregon continental margin using integrated interpretive GIS techniques [Masters Thesis]: Corvallis, Oregon State University, 87p
Online Linkage: http://activetectonics.coas.oregonstate.edu/downloads/romsos_final_thesis_all.pdf

Source Time Period of Content:

Time Period Information:

Single Date/Time:

Time of Day: Unknown

Source Citation Abbreviation: Surficial Geolgic Habitat, Version 1

Source Information:

Source Citation:

Citation Information:

Originator: Romsos, C.G.
Publication Date: 2007
Title: Surficial Geologic Habitat, Version 2
Other Citation Details:
Romsos, C.G., Goldfinger, C., Robison, R., Milstein, R.L., Chaytor, J.D., and Wakefield, W.W., 2007, Development of a regional seafloor surficial geologic habitat map for the continental margins of Oregon and Washington, USA, in Todd, B.J., and Greene, H.G., eds., Mapping the Seafloor for Habitat Characterization: Geological Association of Canada, Special Paper 47, p. 219-243.
Source Time Period of Content:

Time Period Information:

Single Date/Time:

Time of Day: Unknown

Source Citation Abbreviation: Surficial Geologic Habitat, Version 2
Source Contribution:
Version 2.0 Attribute Table Changes Include:
(1) The addition of a second SGH habitat attribute class, "GEO_HAB2", which is identical to the "GEO_HAB" attribute code in most cases except where a Version 1 or 2 polygon falls within the areas: (1) remaped by Lanier (previously unpublished data and Lanier 2006 MS Thesis), or (2) within the Territorial Sea of Oregon (Cmpletely remapped for Version3). Again, the original classification coding from Version 1 or 2 is retained in the "GEO_HAB" attribute field and polygons that have been remaped and recoded, by Lanier, are denoted with an asterisk (*) after the GEO_HAB attribute code. Territorial Sea polygons have a "NA" GEO_HAB attribute because the new mapping superceeds the old mapping. The new code is a more detailed interpretation of Simrad em300 multibeam bathymetry and backscatter data on the northern Oregon outer continental shelf and upper slope. The Greene et al. 2005 classification scheme was modified slightly to fit our interpretation of the data.

Example:

GEO_HAB = She* -- Original Version 1 or 2 habitat polygon attribute coding, * denotes a remaping occured
GEO_HAB2 = She/s_d -- Updated habitat polygon attribute code after remaping.

What this means: The original maps (Versions 1 & 2) classified this polygon as rocky shelf. Subsequent mapping with additional data reveals something more about the composition of this polygon (see Overview citation code descriptions). It's still a rocky shelf habitat so the "GEO_HAB" code remains valid. the GEO_HAB2 provides the enhanced classification. Both attribute fields are kept because we can't enhance every polygon in the map until the appropriate data is collected at which point the "GEO_HAB" attribute field will become deprecated.

(2) We have added 3 new attribute fields (SGH_prefix, SGH_lith1, and SGH_lith2) These attributes fields are included to provide a more accurate cross-database mapping of seafloor habitats to species habitat preferences. More specifically, this dataset is bieng developed in harmony with the NOAA Fisheries NWFSC Habitat Use Database of HUD (a collection of habitat prefrences by species and lifestage for westcoast groundfish). We found the Version 1 and 2 "Geo_Hab" attribute codes (after Greene et. al) difficult to map to the HUD which uses a slightly different habitat classification scheme. Most simply, we've simplified the "Geo_Hab" attribute code into a 2 character code we call "SGH_prefix" without losing any information that is useful for identifying species-habitat relationships from the HUD database.

Source Information:

Source Citation:

Citation Information:

Originator: Active Tectonics and Seafloor Mapping Lab
Publication Date: 2009
Title: Surficial Geologic Habitat, Version 3
Other Citation Details:
Melinda Agapito M.S. 2008; Mapping and Lithologic interpretation of the Territorial Sea, Oregon

Online Linkage: http://ir.library.oregonstate.edu/xmlui/bitstream/handle/1957/9441/agapito_thesis_all_2008_wofl.pdf?sequence=1

Source Time Period of Content:

Time Period Information:

Single Date/Time:

Time of Day: Unknown

Source Citation Abbreviation: Surficial Geologic Habitat, Version 3
Source Contribution:
Version 3.0 interpretation is detailed in Melinda Agapito's MS Thesis (2008, College of Oceanic and Atmospheric Science, Oregon State University, Corvallis, OR 97331). In brief, the new territorial sea mapping followed a compatible interpretation method but utilized previously unknown and unavailable historic data from the U.S. Office of Coast and Geodetic Survey (Now the National Ocean Service).
Source Information:

Source Citation Abbreviation: Surficial Geologic Habitat, Version 3.5
Source Contribution:
This Version 3.5 product represents a significant revision to earlier SGH maps for Oregon. The most significant change is the hand digitization of habitat types in the vicinity of pilot and proposed marine reserves within Oregon's territorial sea (generally, the first 3 nm from the beach). This revision was completed through visual interpretation of both bathymetric and backscatter and ground truth data collected subsequent to the release of the Version 3.0 map.
Version 3.5 Attribute Table Changes Include:

GeoHab2 attribute field was dropped for Version 3.5 because it was not maintianed well and we do not have confidence that it represented anything meaningful anymore.

Source Information:

Source Citation Abbreviation: Surficial Geologic Habitat, Version 3.6
Source Contribution:
Version 3.6 was generated by NOAA collaborators as a merge between v3.1 within offshore federal waters (Surficial Geologic Habitat maps for the Washington and Oregon continental marginsÂ’) and v3.5 within the extent of Oregon's Terrestrial Sea (Interim Surficial Geologic Habitat Map for the Oregon Territorial Sea.Â’)
Process Step:

Process Description:
The data presented in this shapefile was modified from the original source (Versions 1 & 2; Romsos 2004, Romsos 2007 and Version 3.0; Agapito 2008) to it's current form Version 3.6.1. Please consult the Source Information section above to understand the changes made at each stage of the evolution of the dataset.
Cloud Cover: 0

Direct Spatial Reference Method: Vector
Point and Vector Object Information:

SDTS Terms Description:

SDTS Point and Vector Object Type: G-polygon
Point and Vector Object Count: 21286

Horizontal Coordinate System Definition:

Planar:

Map Projection:

Map Projection Name: Lambert Conformal Conic
Lambert Conformal Conic:

Standard Parallel: 43
Standard Parallel: 45.5
Longitude of Central Meridian: -120.5
Latitude of Projection Origin: 41.75
False Easting: 1312335.958005
False Northing: 0

Planar Coordinate Information:

Planar Coordinate Encoding Method: Coordinate Pair
Coordinate Representation:

Abscissa Resolution: 0
Ordinate Resolution: 0

Planar Distance Units: international feet

Geodetic Model:

Horizontal Datum Name: North American Datum of 1983
Ellipsoid Name: Geodetic Reference System 80
Semi-major Axis: 6378137
Denominator of Flattening Ratio: 298.257

Detailed Description:

Entity Type:

Entity Type Label: BenthicHab_v3_6_1

Attribute:

Attribute Label: Comments

Attribute:

Attribute Label: FID
Attribute Definition: Internal feature number.
Attribute Definition Source: ESRI
Attribute Domain Values:

Unrepresentable Domain: Sequential unique whole numbers that are automatically generated.

Attribute:

Attribute Label: Geo_Hab_1
Attribute Definition: Habitat class definitions. Habitat code developed for the EFH Programatic EIS, 2005.
Attribute Domain Values:

Enumerated Domain:

Enumerated Domain Value: Bhe
Enumerated Domain Value Definition: Basin, hard substrate

Enumerated Domain:

Enumerated Domain Value: Bs_u
Enumerated Domain Value Definition: Basin, unconsolidated substrate

Enumerated Domain:

Enumerated Domain Value: Fhc
Enumerated Domain Value Definition: Canyon Wall, hard substrate

Enumerated Domain:

Enumerated Domain Value: Fhe
Enumerated Domain Value Definition: Slope, hard substrate

Enumerated Domain:

Enumerated Domain Value: Fhl
Enumerated Domain Value Definition: Mass Wasting Zone, hard substrate

Enumerated Domain:

Enumerated Domain Value: Fs_u
Enumerated Domain Value Definition: Slope, unconsolidated substrate

Enumerated Domain:

Enumerated Domain Value: Fsc/f_u
Enumerated Domain Value Definition: Canyon Floor, unconsolidated substrate

Enumerated Domain:

Enumerated Domain Value: Fsc_u
Enumerated Domain Value Definition: Canyon Wall, unconsolidated substrate

Enumerated Domain:

Enumerated Domain Value: Fsl
Enumerated Domain Value Definition: Mass Wasting Zone, unconsolidated substrate

Enumerated Domain:

Enumerated Domain Value: Rhe
Enumerated Domain Value Definition: Ridge, hard substrate

Enumerated Domain:

Enumerated Domain Value: Rs_u
Enumerated Domain Value Definition: Ridge, unconsolidated substrate

Enumerated Domain:

Enumerated Domain Value: She
Enumerated Domain Value Definition: Shelf, hard substrate

Enumerated Domain:

Enumerated Domain Value: Ss_u
Enumerated Domain Value Definition: Shelf, unconsolidated substrate

Attribute:

Attribute Label: Geo_Hab_2
Attribute Definition:
Habitat class definitions. Updated habitat polygon attribute code after remapping. Identical to the "GEO_HAB" attribute code in most cases except where a Version 1 or 2 polygon falls withing the following areas: (1) remaped by Lanier (previously unpublished data and Lanier 2006 MS Thesis), or (2) within the Territorial Sea of Oregon (Cmpletely remapped for Version3). See overview description below for more information.
Attribute Domain Values:

Enumerated Domain:

Enumerated Domain Value: Bhe_d/u
Enumerated Domain Value Definition: Basin, hard substrates, exposed bedrock that is differentially eroded and mixed with unconsolidated sediment.

Enumerated Domain:

Enumerated Domain Value: Bm(b)_f
Enumerated Domain Value Definition: Basin, mixed substrates (including boulders), and flat or valley floor

Enumerated Domain:

Enumerated Domain Value: Bm(b)e_l/u
Enumerated Domain Value Definition: Basin, mixed substrates, with exposed carbonates (l) and unconsolidated sediments

Enumerated Domain:

Enumerated Domain Value: Bs(m)_f
Enumerated Domain Value Definition: Basin, soft sediments (mud), on the flat, valley floor

Enumerated Domain:

Enumerated Domain Value: Fhe_d/u
Enumerated Domain Value Definition: Continental Slope, hard substrates, including differentially eroded exposed bedrock and unconsolidated sediments.

Enumerated Domain:

Enumerated Domain Value: Fhe_l
Enumerated Domain Value Definition: Continental Slope, hard substrates, including exposed carbonates

Enumerated Domain:

Enumerated Domain Value: Fhe_h/u
Enumerated Domain Value Definition: Continental Slope, hard substrates, and exposed, hummocky bedrock and unconsolidated sediments

Enumerated Domain:

Enumerated Domain Value: Fm(b)e_c/u
Enumerated Domain Value Definition: Continental Slope, mixed substrates (boulders present) along with exposed, consolidated sediment (mudstone) and unconsolidated sediments

Enumerated Domain:

Enumerated Domain Value: Fm(b)_l
Enumerated Domain Value Definition: Continental Slope, mixed substrates, including carbonate boulders

Enumerated Domain:

Enumerated Domain Value: Fmd_h/u
Enumerated Domain Value Definition: Continental Slope, mixed substrates, including deformed, tilted and folded, hummocky bedrock and unconsolidated sediments

Enumerated Domain:

Enumerated Domain Value: Fme
Enumerated Domain Value Definition: Continental Slope, mixed substrates and exposed bedrock

Enumerated Domain:

Enumerated Domain Value: Fme_d/u
Enumerated Domain Value Definition: Continental Slope, hard substrates and exposed, differentially eroding bedrock and unconsolidated sediments

Enumerated Domain:

Enumerated Domain Value: Fme_d/u_l
Enumerated Domain Value Definition: Continental Slope, mixed substrates and exposed, differentially eroding carbonate bedrock and unconsolidated sediments

Enumerated Domain:

Enumerated Domain Value: Fme_h/u
Enumerated Domain Value Definition: Continental Slope, mixed substrates, including exposed, hummocky bedrock and unconsolidated sediments

Enumerated Domain:

Enumerated Domain Value: Fme_l
Enumerated Domain Value Definition: Continental Slope, mixed substrates, and exposed carbonate rocks

Enumerated Domain:

Enumerated Domain Value: Fml
Enumerated Domain Value Definition: Continental Slope, mixed substrates, landslide

Enumerated Domain:

Enumerated Domain Value: Fmg_b/u
Enumerated Domain Value Definition: Continental Slope, mixed substrates, within a gully or channel and is composed of a bimodal mix of unconsolidated sediments

Enumerated Domain:

Enumerated Domain Value: Fs(m)_f
Enumerated Domain Value Definition: Continental Slope, soft substrates (mud), on a flat area or valley floor

Enumerated Domain:

Enumerated Domain Value: Fsg
Enumerated Domain Value Definition: Continental Slope, soft substrates, in a gully or channel

Enumerated Domain:

Enumerated Domain Value: Rh(bc)e_c/u
Enumerated Domain Value Definition: Ridge or Seamount, hard substrates (consisting of boulders and cobbles), and exposed bedrock of consolidated sediment, with minor amounts of unconsolidated sediments

Enumerated Domain:

Enumerated Domain Value: Rh(bc)e_d/u_l
Enumerated Domain Value Definition: Ridge or Seamount, hard substrates (consisting of boulders and cobbles), and exposed, differentially eroded carbonates and unconsolidated sediments

Enumerated Domain:

Enumerated Domain Value: Rhe/g_i
Enumerated Domain Value Definition: Ridge or Seamount, hard substrates, and exposed bedrock within a gully, rockwall interface

Enumerated Domain:

Enumerated Domain Value: Rhe_d/u
Enumerated Domain Value Definition: Ridge or Seamount, hard substrates, and exposed bedrock that is differentially eroded, with minor amounts of unconsolidated sediments

Enumerated Domain:

Enumerated Domain Value: Rme_d/u_l
Enumerated Domain Value Definition: Ridge or Seamount, mixed substrates, with exposed differentially eroding carbonate bedrocks and minor amounts of unconsolidated sediments

Enumerated Domain:

Enumerated Domain Value: Rme_h/u
Enumerated Domain Value Definition: Ridge or Seamount, mixed substrates, with exposed hummocky bedrock and minor amounts of unconsolidated sediments

Enumerated Domain:

Enumerated Domain Value: Sh(b)e/p_u
Enumerated Domain Value Definition: Continental Shelf, hard substrates including exposed bedrock, pinnacles, boulders, and unconsolidated sediment

Enumerated Domain:

Enumerated Domain Value: She/s_d
Enumerated Domain Value Definition: Continental Shelf, hard substrates, exposed bedrock, and differentially eroded bedrock scarp

Enumerated Domain:

Enumerated Domain Value: She_d
Enumerated Domain Value Definition: Continental Shelf, hard substrates, differentially eroded bedrock

Enumerated Domain:

Enumerated Domain Value: She_V(?)
Enumerated Domain Value Definition: Continental Shelf, hard substrates and exposed bedrock, possibly volcanic

Enumerated Domain:

Enumerated Domain Value: Sm(b)e/p
Enumerated Domain Value Definition: Continental Shelf, mixed substrates, with exposed bedrock, boulders, and pinnacles

Enumerated Domain:

Enumerated Domain Value: Sh(b)e/p_u
Enumerated Domain Value Definition: Continental Shelf, hard substrates including boulders and pinnacles

Enumerated Domain:

Enumerated Domain Value: Sm(b)p
Enumerated Domain Value Definition: Continental Shelf, mixed substrates, boulders, and pinnacles

Enumerated Domain:

Enumerated Domain Value: Sm(bcs)e/p
Enumerated Domain Value Definition: Continental Shelf, mixed substrates (boulders, cobbles, and sand), with exposed bedrock and pinnacles

Enumerated Domain:

Enumerated Domain Value: Smf_u
Enumerated Domain Value Definition: Continental Shelf, mixed substrates, on flat floor or in minor depressions (f(d)) or crests (f(c)) with unconsolidated sediments

Enumerated Domain:

Enumerated Domain Value: Smd_d/u
Enumerated Domain Value Definition: Continental Shelf, mixed substrates, local unconsolidated sediment covered differentially eroded, deformed/tilted/folded bedrock

Enumerated Domain:

Enumerated Domain Value: Smd_h/u
Enumerated Domain Value Definition: Continental Shelf, mixed substrates, local unconsolidated sediment covered deformed/tilted/folded, hummocky bedrock

Enumerated Domain:

Enumerated Domain Value: Sme_h/u
Enumerated Domain Value Definition: Continental Shelf, mixed substrates, local unconsolidated sediment covered hummocky bedrock

Enumerated Domain:

Enumerated Domain Value: Smk
Enumerated Domain Value Definition: Continental Shelf, mixed substrates, with bedrock and unconsolidated sediment pockmarks (sink or pit)

Enumerated Domain:

Enumerated Domain Value: Ssm_s/u
Enumerated Domain Value Definition: Continental Shelf, soft substrates, in mounds (m(c)) or depressions (m(d)) resulting from scours, unconsolidated sediments present

Enumerated Domain:

Enumerated Domain Value: Ssf_u
Enumerated Domain Value Definition: Continental Shelf, soft substrates, on floor or in depressions (f(d)) with unconsolidated sediments

Attribute:

Attribute Label: HUD_LU
Attribute Definition: NOAA Fisheries NWFSC Habitat Use Database (a collection of habitat prefrences by species and lifestage for westcoast groundfish)

Attribute:

Attribute Label: NEDA_rclas
Attribute Definition:
A simplified reclassification of habitat types was applied by TNC staff per the field [NEDA_reclas]. Two rulesets for the reclassification were necessary owing to differences in the original classifications: one was applied to WA and OR; the other to CA. For WASHINGTON and OREGON: (1) Habitat type 'Rock' = either SGH_Lith_1 or SGH_Lith_2 type is 'rock', 'boulder', or 'boulder/sand'; (2) Habitat type 'Sand' = Both SGH types are sand, or SGH_Lith_1 is sand and SGH_Lith_2 is mud, or SGH_Lith_1 is sand and SGH_Lith_2 is blank. . (note: the single polygon with SGH_Lith_1 of Sand and a SGH_Lith_2 of mud/shell was classed as Sand); (3) Habitat type 'Mud' = Both SGH types are mud, or SGH_Lith_1 is mud and SGH_Lith_2 is sand, or SGH_Lith_1 is mud and SGH_Lith_2 is blank. (4) Habitat type 'Gravel, Cobble, Shell, or Mixed' = all other combinations that donÂ’t fit into one of the 3 preceding categories . For CALIFORNIA: (1) 'Rock' = SGH_Lith_1 or SGH_Lith_2 is 'rock' or 'island'; (2) 'Sand' = SGH_Lith_1 and/or SGH_Lith_2 is 'soft' and depth is 200m; (4) 'Gravel, Cobble, Shell, or Mixed' = all other combinations that donÂ’t fit into one of the 3 preceding categories.
Attribute:

Attribute Label: Phys_Hab

Attribute:

Attribute Label: Phys_Hab2

Attribute:

Attribute Label: PLACENAME

Attribute:

Attribute Label: SGH_Lith_1
Attribute Definition:
Primary surficial lithologic or sedimentary characteristics of the polygon. "SGH_lith1" is our best estimate of whats most abundant in the polygon. In most cases we've no means to quantitaively measure lithologic or sedementary composition, therefore the vast majority of polygons only include a primary lithology.
Attribute:

Attribute Label: SGH_Lith_2
Attribute Definition:
Secondary surficial lithologic or sedimentary characteristics of the polygon. and "SGH_lith2" is what follows that in abundance. In most cases we've no means to quantitaively measure lithologic or sedementary composition, therefore the vast majority of polygons only include a primary lithology.
Attribute:

Attribute Label: SGH_Lith_3

Attribute:

Attribute Label: SGH_PREFIX
Attribute Definition:
Surficial Geologic Habitat prefix. A 2-digit simplification or reduction of the "GEO_HAB" attribute field for use with mapping habitat polygons to habitat preferences in the Habitat Use Database (NOAA, NWFSC). SGH_prefix is our attempt to better map habitats to the L1, L2, and L3 HUD habitat preferences.
Attribute Domain Values:

Enumerated Domain:

Enumerated Domain Value: Ns
Enumerated Domain Value Definition: Nearshore, unconsolodated (soft)

Enumerated Domain:

Enumerated Domain Value: Nh
Enumerated Domain Value Definition: Nearshore, rocky (hard)

Enumerated Domain:

Enumerated Domain Value: Nm
Enumerated Domain Value Definition: Nearshore, mixed

Enumerated Domain:

Enumerated Domain Value: Ss
Enumerated Domain Value Definition: Shelf, unconsolodated (soft)

Enumerated Domain:

Enumerated Domain Value: Sh
Enumerated Domain Value Definition: Shelf, rocky (hard)

Enumerated Domain:

Enumerated Domain Value: Sm
Enumerated Domain Value Definition: Shelf, mixed

Enumerated Domain:

Enumerated Domain Value: Fs
Enumerated Domain Value Definition: Flank (Slope), unconsolodated (soft)

Enumerated Domain:

Enumerated Domain Value: Fh
Enumerated Domain Value Definition: Flank (Slope), rocky (hard)

Enumerated Domain:

Enumerated Domain Value: Fm
Enumerated Domain Value Definition: Flank (Slope), mixed

Enumerated Domain:

Enumerated Domain Value: Cs
Enumerated Domain Value Definition: Canyon, unconsolodated (soft)

Enumerated Domain:

Enumerated Domain Value: Ch
Enumerated Domain Value Definition: Canyon, rocky (hard)

Enumerated Domain:

Enumerated Domain Value: Cm
Enumerated Domain Value Definition: Canyon, mixed

Attribute:

Attribute Label: Shape
Attribute Definition: Feature geometry.
Attribute Definition Source: ESRI
Attribute Domain Values:

Unrepresentable Domain: Coordinates defining the features.

Attribute:

Attribute Label: Shape_area
Attribute Definition: Area of feature in meters squared.
Attribute Definition Source: ESRI
Attribute Domain Values:

Unrepresentable Domain: Positive real numbers that are automatically generated.

Attribute:

Attribute Label: Shape_Le_1
Attribute Definition: Perimeter of feature in meters.

Attribute:

Attribute Label: SUBCLASS

Overview Description:

Entity and Attribute Overview:
The data presented in this shapefile was modified from the original source (Versions 1 & 2; Romsos 2004, Romsos 2007 and Version 3.0; Agapito 2008) to it's current form Version 3.6.1. Please consult the Source Information section above to understand the changes made at each stage of the evolution of the dataset.

Resource Description: Downloadable Data
Distribution Liability:
Use of these data is restricted to entities of the State of Oregon for internal evaluation only. Any use of these data constitutes an understanding that this data-set represents a work-in-progress which is accompanied by no guarantee of accuracy.
Standard Order Process:

Digital Form:

Digital Transfer Information:

Format Name: Shapefile
Transfer Size: 29.854

Available Time Period:

Time Period Information:

Single Date/Time:

Calendar Date: 1/1/1895
Time of Day: Unknown

Metadata Date: 1/6/2012
Metadata Review Date:
Metadata Future Review Date:
Metadata Contact:

Contact Information:

Contact Organization Primary:

Contact Organization: Active Tectonics & Seafloor Mapping Lab
Contact Person: Chris Romsos

Contact Position: Faculty Research Assistant
Contact Address:

Address Type: mailing address
Address: 104 COAS Admin. Bldg., Oregon State University
City: Corvallis
State or Province: OR
Postal Code: 97330
Country: USA

Contact Voice Telephone: 541-737-2898
Contact Electronic Mail Address: cromsos@coas.oregonstate.edu

Metadata Standard Name: FGDC Content Standards for Digital Geospatial Metadata
Metadata Standard Version: FGDC-STD-001-1998
Metadata Time Convention: local time
