Submarine Cables, OFCC, 2012

Citation:

Citation Information:

Originator: Oregon Fishermens Cable Committee
Publication Date: 20101231
Title: Submarine Cables, OFCC, 2012
Geospatial Data Presentation Form: vector digital data

Description:

Abstract: This data represesntss the locations of submarine cables that make landing ont he Oregon coast.
Purpose:
This data represents the locations of underwater cables that make a landing on the Oregon coast. These cables are usesd in telecommunication, research, and power. They were compiled by the Oregon Fishermens Cable Committee, in agreement with cable operators, delineate cable routes and avoid space use conflicts between cables and trawl fishermen. The data were also used in Oregon's Territorial Sea Planning process to understand where conflict between submarine cables and wave energy devices might occur.
Time Period of Content:

Time Period Information:

Single Date/Time:

Calendar Date: 12/31/2012
Time of Day: Unknown

Currentness Reference: publication date

Status:

Progress: In work
Maintenance and Update Frequency: As needed

Spatial Domain:

Bounding Coordinates:

West Bounding Coordinate: -130.020122
East Bounding Coordinate: -123.64014
North Bounding Coordinate: 46.459993
South Bounding Coordinate: 40.229599

Keywords:

Theme:

Theme Keyword Thesaurus: None
Theme Keyword: submarine cables
Theme Keyword: oregon territorial sea plan

Theme:

Theme Keyword Thesaurus: ISO 19115 Topic Categories
Theme Keyword: oceans
Theme Keyword: utilitiesCommunication

Access Constraints: None
Use Constraints: The exact location of the cabless are protected by law to discourage tampering.
Point of Contact:

Contact Information:

Contact Organization Primary:

Contact Organization: Oregon Fishermens Cable Committee
Contact Person: Scott Mcmullen

Contact Position: Chair
Contact Address:

Address Type: mailing
Address: 2021 Marine Drive
City: Astoria
State or Province: OR
Postal Code: 97103

Contact Voice Telephone: 503-325-2285
Contact Electronic Mail Address: smcmullen@ofcc.com

Data Set Credit: Oregon Fishermens Cable Committee

Direct Spatial Reference Method: Vector
Point and Vector Object Information:

SDTS Terms Description:

SDTS Point and Vector Object Type: G-polygon
Point and Vector Object Count: 15

Horizontal Coordinate System Definition:

Planar:

Map Projection:

Map Projection Name: Lambert Conformal Conic
Lambert Conformal Conic:

Standard Parallel: 43
Standard Parallel: 45.5
Longitude of Central Meridian: -120.5
Latitude of Projection Origin: 41.75
False Easting: 1312335.958005
False Northing: 0

Planar Coordinate Information:

Planar Coordinate Encoding Method: Coordinate Pair
Coordinate Representation:

Abscissa Resolution: 0
Ordinate Resolution: 0

Planar Distance Units: international feet

Geodetic Model:

Horizontal Datum Name: North American Datum of 1983
Ellipsoid Name: Geodetic Reference System 80
Semi-major Axis: 6378137
Denominator of Flattening Ratio: 298.257

Detailed Description:

Entity Type:

Entity Type Label: SubmarineCables_OFCC_2012

Attribute:

Attribute Label: BUFF_DIST
Attribute Definition: The distance around the cable that is buffered for safety.

Attribute:

Attribute Label: FID
Attribute Definition: Internal feature number.
Attribute Definition Source: ESRI
Attribute Domain Values:

Unrepresentable Domain: Sequential unique whole numbers that are automatically generated.

Attribute:

Attribute Label: NAME

Attribute:

Attribute Label: Shape
Attribute Definition: Feature geometry.
Attribute Definition Source: ESRI
Attribute Domain Values:

Unrepresentable Domain: Coordinates defining the features.

Attribute:

Attribute Label: Shape_Area
Attribute Definition: Area of feature in internal units squared.
Attribute Definition Source: Esri
Attribute Domain Values:

Unrepresentable Domain: Positive real numbers that are automatically generated.

Attribute:

Attribute Label: Shape_Leng

Resource Description: Downloadable Data
Distribution Liability: The exact location of the cables are protected by law to discourage tampering.
Standard Order Process:

Digital Form:

Digital Transfer Information:

Format Name: Shapefile
Transfer Size: 0

Metadata Date: 9/23/2013
Metadata Review Date:
Metadata Future Review Date:
Metadata Contact:

Contact Information:

Contact Organization Primary:

Contact Organization: Oregon Fishermens Cable Committee
Contact Person: Scott Mcmullen

Contact Position: Chair
Contact Address:

Address Type: mailing
Address: 2021 Marine Drive
City: Astoria
State or Province: OR
Postal Code: 97103

Contact Voice Telephone: 503-325-2285
Contact Electronic Mail Address: smcmullen@ofcc.com

Metadata Standard Name: FGDC Content Standards for Digital Geospatial Metadata
Metadata Standard Version: FGDC-STD-001-1998
Metadata Time Convention: local time
