Electrical Substations, BPA, 2010

Citation:

Citation Information:

Originator: Bonneville Power Administration
Publication Date: 20090101
Title: Electrical Substations, BPA, 2010
Geospatial Data Presentation Form: vector digital data

Description:

Abstract: BPA and non-BPA transmission facilities for which BPA has an interest. Facilities include substations, switchyards, compensation stations and other related facilities.
Purpose: To show general point locations of BPA facilities.

Time Period of Content:

Time Period Information:

Single Date/Time:

Calendar Date: 2010
Time of Day: Unknown

Currentness Reference: publication date

Status:

Progress: Complete
Maintenance and Update Frequency: As needed

Spatial Domain:

Bounding Coordinates:

West Bounding Coordinate: -124.702306
East Bounding Coordinate: -118.033309
North Bounding Coordinate: 46.242963
South Bounding Coordinate: 41.940175

Keywords:

Theme:

Theme Keyword Thesaurus: Content Standard for Digital Geospatial Metadata (CSDGM)
Theme Keyword: utilitiesCommunication

Theme:

Theme Keyword Thesaurus: ISO 19115 Topic Categories
Theme Keyword: utilitiesCommunication

Place:

Place Keyword Thesaurus: None
Place Keyword: Oregon

Access Constraints: None. Public Data.
Use Constraints:
Data Disclaimer NOTICE: Data files provided are to be used only to determine the general location of BPA facilities; they are not to be used to locate facilities in relationship to property lines, section lines, streets, or any other acceptable survey techniques.
Point of Contact:

Contact Information:

Contact Organization Primary:

Contact Organization: Bonneville Power Administration
Contact Person: Doug Wittren

Contact Position: Team Lead - GIS, Geospatial Services Department
Contact Voice Telephone: 360-619-6608
Contact Electronic Mail Address: dlwittren@bpa.gov

Data Set Credit: Bonneville Power Administration Geospatial Services Department
Native Data Set Environment: Microsoft Windows XP Version 5.1 (Build 2600) Service Pack 3; ESRI ArcCatalog 9.3.0.1770

Direct Spatial Reference Method: Vector
Point and Vector Object Information:

SDTS Terms Description:

SDTS Point and Vector Object Type: Entity point
Point and Vector Object Count: 165

Horizontal Coordinate System Definition:

Planar:

Map Projection:

Map Projection Name: Lambert Conformal Conic
Lambert Conformal Conic:

Standard Parallel: 43
Standard Parallel: 45.5
Longitude of Central Meridian: -120.5
Latitude of Projection Origin: 41.75
False Easting: 1312335.958005
False Northing: 0

Planar Coordinate Information:

Planar Coordinate Encoding Method: Coordinate Pair
Coordinate Representation:

Abscissa Resolution: 0
Ordinate Resolution: 0

Planar Distance Units: international feet

Geodetic Model:

Horizontal Datum Name: North American Datum of 1983
Ellipsoid Name: Geodetic Reference System 80
Semi-major Axis: 6378137
Denominator of Flattening Ratio: 298.257

Detailed Description:

Entity Type:

Entity Type Label: Electrical_Substations_BPA_2010

Attribute:

Attribute Label: FID
Attribute Definition: Internal feature number.
Attribute Definition Source: Esri
Attribute Domain Values:

Unrepresentable Domain: Sequential unique whole numbers that are automatically generated.

Attribute:

Attribute Label: NAME
Attribute Definition: Facility name

Attribute:

Attribute Label: OBJECTID
Attribute Definition: Internal feature number.
Attribute Definition Source: ESRI
Attribute Domain Values:

Unrepresentable Domain: Sequential unique whole numbers that are automatically generated.

Attribute:

Attribute Label: owner
Attribute Definition: Facility owner

Attribute:

Attribute Label: Shape
Attribute Definition: Feature geometry.
Attribute Definition Source: ESRI
Attribute Domain Values:

Unrepresentable Domain: Coordinates defining the features.

Attribute:

Attribute Label: STA_CODE
Attribute Definition: 4 letter ID code

Attribute:

Attribute Label: TYPE
Attribute Definition: Facility type

Resource Description: Downloadable Data
Standard Order Process:

Digital Form:

Digital Transfer Information:

Transfer Size: 0.005

Metadata Date: 9/23/2013
Metadata Review Date:
Metadata Future Review Date:
Metadata Contact:

Contact Information:

Contact Organization Primary:

Contact Organization: Dept. of Land Conservation and Development
Contact Person: Andy Lanier

Contact Position: Coastal Resource Specialist
Contact Address:

Address Type: mailing and physical address
Address: 635 Capitol St. NE
City: Salem
State or Province: OR
Postal Code: 97301

Contact Voice Telephone: 503.373.0050
Contact Electronic Mail Address: Andy.Lanier@state.or.us
Contact Instructions: Email preferred.

Metadata Standard Name: FGDC Content Standards for Digital Geospatial Metadata
Metadata Standard Version: FGDC-STD-001-1998
Metadata Time Convention: local time
